Harmsco HUR 40 HP, Hurricane Filter Housing
Features
- Combination cyclone separator and cartridge filter in a single compact design
- Patened up-flow design with tangential entry - prevents air entrapment
- Rotational flow "flutters" media pleats - improving loading performance
- Electropolished 304 Stainless stell housing
- Fail-Safe lid closure, rated for 150 psi
- Three sizes for greater surface area
- CPVC standpipe (standard) - stainless steel optional
- Extensive choice of cartridge micron ratings and media, including carbon block
- NSF 61 listed
- Maunfactured in the USA
Applications
- Commercial/Residential Drinking Water - Industrial Waste Water Treatment
- Cooling Tower Filtration - Reverse Osmosis Pre-Filtration
- Desalination Pre-Filtration (316 & Coated Options) - Small community compliance (LT2)
- Surface Water Treatment Rule (SWTR) LT2 - Well Water
- Process Water - Ground water remediation
- Whole House Filtration - Ground water under direct influence (GUDI)
- Holds (1) Hurricane Cartridge
| Filter Model | HUR 40 HP |
| Height | 19-1/2" |
| Width | 14-3/8" |
| Diameter | 13" |
| Inlet Height | 12-3/4" |
| Outlet Height | 3-7/16" |
| Pipe Size NPT | 2" |
| Drain Size | 1" |
| Floor Space | 15" x 15" |
| Service Height | 35" |
| Shipping Weight | 40 lbs. |
| Recommended Flow Rate | Up To 35 GPM |
| Max. Flow Rate | Up To 50 GPM |
- Electropolished 304 stainless steel finish
- Standpipe - CPVC
- Wing nuts - brass
- Rim gaskets - EPDM (Buna-N, Viton available)
- BSTP optional
- Pressure - up to 150 psi (10 bar) max
- Temperature - up to 140°F (60° C) max. Up to 250°F (121°C) with optional stainless steel standpipe and high temperature cartridges installed.
