Harmsco HIF 21, Up-Flow Cartridge Housing
Features
- 304 Stainless steel construction, standard
- Electropolished finish, standard
- 150 psi (10.3 bar) pressure rating
- Flow rates up to 800 GPM
- All filter housings hydrostatically tested
- Easy cartridge installtion, removal and service
- Individual studs for safe, secure lid closure
- Extensive choice of cartridge micron ratings and media
- Manufactured in the USA
Options
- 316 Stainless steel
- Chemical resisten coating
- Flanged options on HIF 24, HIF 42, HIF 75 and HIF 100
Applications
- Commercial/Residential Drinking Water - Industrial Waste Water Treatment
- Cooling Tower Filtration - Reverse Osmosis Pre-Filtration
- Process Water - Ground water remidiation
- Surface Water Treatment Rule (SWTR) LT2 - Utility Water
| Filter Model | HIF 21 |
| Height | 37" |
| Diameter | 13" |
| Leg Width | 13" |
| Inlet Height | 3-1/2" |
| Service Height | 68" |
| Inlet/Outlet | 1-1/2" NPT |
| Drain Size NPT | 1" |
| Flow Rate* (GPM) | Up to 90 |
| Flow Rate* (LPM) | Up to 340 |
| Flow Rate* (M3/HR) | Up to 20 |
| Cartridges | (7) 29-1/4" "Triples" |
- Filter Vessel/Metal Components - 304 stainless steel, electropolished for increased resistance to corrosion
- Holding/Lifting Rods, Standpipes and Pipe Caps - CPVC, standard models; 304 stainless steel for All Stainless models
- Rim Gaskets - EPDM, standard; Buna-N, Viton Available
- O-Rings - Buna-N Standard; EPDM, Viton Available
- Bottom Seals - natural gum rubber, standard; EPDM, Viton Available
- Pressure - rated for presure to 150 psi (10.3 bar) max
- Temperature - rated for 140°F (60°C) with CPVC rods, pipe caps, standpipes and standard Harmsco cartridges; to 200°F (93°C) for all stainless models with stainless steel rods, pipe caps and standpipes and Harmsco High-temp cartridges
- Wing Nuts - brass; optional brass hex nuts and stainless steel flat washers
