CPF Glass Depth Cartridge, 20 Micron Rating, GGD20, General Grade

GGD grade Fiber Glass Depth cartridges are designed for general purpose use wherever a cost effective pleated Fiber Glass Depth filter is required. 99% efficiencies at the rated pore size and designed to hold the maximum amount of filter media that can be completely and effectively utilized in a cartridge. GGD cartridges are flushed with 17+ megohm-cm water to remove potential extraneous manufacturing debris. These cartridge modules are also individually tested.

Maximum Operating Parameters

• Micron Rating: 20 Micron
• Maximum Operating Temperature^*: 180°F (82°C) at 10 psid in water
• Forward Differential Pressure: 50 psi (3.4 bar) at 20°C
• Reverse Differential Pressure: 40 psi (2.7 bar) at 20°C
• Recommended Changeout Pressure: 35 psid (2.4 psid)

Dimensions

• Length: 5 to 40" (12.7 101.6 cm) nominal
• Outside Diameter: 2.75" (7.0 cm) nominal
• Surface Area: 6.8 ft² (0.63 m²) Per 10" length

Applications
Pre Filtration of:

• Wine Clarification                    • Soft Drinks
• Beverage Clarification              • Bottled Water
• Cosmetics                                 • Process Water

• Syrups                                      • Air
