Blue-White TB-150AT-GPM1, 15 to 150 GPM, 1-1/2" IPS Pipe Size Paddlewheel Flowmeter, F-1000 Series
Total Only
Solvent Weld PVC Tee Body
- Easy to read 6 digit LCD, up to 4 decimal positions
- Tamper Proof
- Battery Operated (2 AAA batteries included)
- 3 Model Variations
- RB = Rate Only
- TB = Total Only
- RT = Rate & Totalizer
- Total reset function can be disabled
- Display update time: Rate: 1.5 sec., Total 0.5 sec.
- Factory calibrated - nothing to program
- Custom calibration units available
- Weather resistant ABS enclosure. NEMA 4X
- LCD is not recommended for direct sunlight applications
| Pipe size | 1-1/2" IPS Pipe Size |
| Low Flow Reading | 15 GPM |
| High Flow Reading | 150 GPM |
| Max Working Pressure | 200 PSI (20 bar) @ 70°F (21°C) |
| Max Fluid Temperature | 140°F (60°C) @ 0 PSI |
| Full Scale Accuracy | +/- 2% |
| Meter Body Material | PVC |
| Sensor/Paddle/Axle Material | PVDF |
| O-Ring Seals | Viton |
| Max Pressure Drop | 0 psi (no significant drop) |
| Approx. Ship Weight | 2 lb (.91 kg) |
| Dimensions | 4" x 6" |
Maximum continuous flow should not occur in the upper 25% of the flow range.
